TrakMotive GM-8187 - CV Axle Shaft
- Part Number
- GM-8187
- Manufacturer
- TRAKMOTIVE
- Description
-
CV Axle Shaft
details
$10849
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
TRAKMOTIVE part description
Product Description
CV Axle Shaft
Product Attributes
| ABS Ring Tooth Count | 48 |
| ABS Ring Type | Toothed |
| Abs Tone Ring Included | Yes |
| Axle Bolt Hex Size (mm) | N/A |
| Axle Bolt Length (mm) | N/A |
| Axle Bolt Thread Size | N/A |
| Axle Nut Head Type | Hex |
| Axle Nut Height (in) | .8 |
| Axle Nut Height (mm) | 20 |
| Axle Nut Hex Size (in) | 1.67 |
| Axle Nut Hex Size (mm) | 30 |
| Axle Nut Included | Yes |
| Axle Nut Length (in) | 1.33 |
| Axle Nut Length (mm) | 34 |
| Axle Nut Locking Type | Self-Lock |
| Axle Nut Thread Size | M20x1.5 |
| Boot Material | Neoprene |
| Inboard Bolt Head Size (in) | N/A |
| Inboard Bolt Head Size (mm) | N/A |
| Inboard Bolt Head Type | N/A |
| Inboard Bolt Length (in) | N/A |
| Inboard Bolt Length (mm) | N/A |
| Inboard Bolt Thread Size | N/A |
| Inboard Joint Type | Female |
| Inboard Shaft Connection Style | Female |
| New Or Remanufactured | New |
| Number of Bolt Holes | 0 |
| Number Of Inboard Joint Bolt Holes | 0 |
| Number Of Inboard Shaft Bolts | 0 |
| Number Of Inboard Splines | 34 |
| Number Of Outboard Joint Bolt Holes | 0 |
| Number Of Outboard Shaft Bolts | 0 |
| Number Of Outboard Splines | 33 |
| Outboard Bolt Head Size (in) | N/A |
| Outboard Bolt Head Size (mm) | N/A |
| Outboard Bolt Head Type | N/A |
| Outboard Bolt Length (in) | N/A |
| Outboard Bolt Length (mm) | N/A |
| Outboard Joint Bolt Thread Size | N/A |
| Outboard Joint Type | Conventional |
| Outboard Shaft Connection Style | Conventional |
| Overall Compressed Length (in) | 20.35 |
| Overall Compressed Length (mm) | 517 |
| Axle Nut Socket Size | 30 |
| Grade Type | Premium |
| Inboard Joint Boot Material | Neoprene |
| Outboard Joint Boot Material | Neoprene |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708508500 |
| UPC | 00844084031877 |
Part Interchanges
- ARC 80-2423
- ARC 80-2425
- ARC 80-2490
- EMPI 80-1363
- Mevotech CV5284
- Carquest 411266
- Carquest 801266
- USA Industries AX-55269
- American Remanufactured 40-16015S
- Fenwick CV2976
- CARDONE Reman 60-1051
- CARDONE Reman 60-1075
- CARDONE Reman 66-1075
- OEM Part Number 26000383
- OEM Part Number 26015028
- OEM Part Number 7845348
- ODM GC-8-8539A
- TrakMotive GM-8187
- 411266
- NCV10503
- 70293
- 179187
- 80-2490
- 92425
Fits Vehicles
- Pontiac J2000 Sunbird (1984-1985)
- Pontiac J2000 (1982-1983)
- Pontiac Grand Am (1985-1995)
- Pontiac 6000 (1982-1983)
- Oldsmobile Firenza (1982-1983)
- Oldsmobile Cutlass Cruiser (1982-1983)
- Oldsmobile Cutlass Ciera (1982-1983)
- Oldsmobile Cutlass Calais (1988-1991)
- Oldsmobile Calais (1985-1987)
- Oldsmobile Achieva (1992-1995)
- Chevrolet Celebrity (1982-1983)
- Chevrolet Cavalier (1982-1983)
- Cadillac Cimarron (1982-1983)
- Buick Somerset Regal (1985)
- Buick Somerset (1986-1987)
- Buick Skylark (1986-1995)
- Buick Skyhawk (1982-1983)
- Buick Century (1982-1983)
