Name: TrakMotive AD8127 CV Axle Shaft
SKU: ad8127
Price: 145.99 USD
Availability: InStock

CV Axle Shaft

ABS Ring Tooth Count	0
ABS Ring Type	N/A
Abs Tone Ring Included	No
Axle Bolt Hex Size (mm)	27
Axle Bolt Length (mm)	97
Axle Bolt Thread Size	M16x1.5
Axle Nut Head Type	N/A
Axle Nut Height (in)	N/A
Axle Nut Height (mm)	N/A
Axle Nut Hex Size (in)	N/A
Axle Nut Hex Size (mm)	N/A
Axle Nut Included	No
Axle Nut Length (in)	N/A
Axle Nut Length (mm)	N/A
Axle Nut Locking Type	N/A
Axle Nut Thread Size	N/A
Boot Material	Neoprene
Inboard Bolt Head Size (in)	.33
Inboard Bolt Head Size (mm)	8
Inboard Bolt Head Type	Allen
Inboard Bolt Length (in)	2.17
Inboard Bolt Length (mm)	55
Inboard Bolt Thread Size	M10x1.5
Inboard Joint Type	Bolt-On
Inboard Shaft Connection Style	Bolt-On
New Or Remanufactured	New
Number of Bolt Holes	1
Number Of Inboard Joint Bolt Holes	6
Number Of Inboard Shaft Bolts	6
Number Of Inboard Splines	0
Number Of Outboard Joint Bolt Holes	0
Number Of Outboard Shaft Bolts	1
Number Of Outboard Splines	36
Outboard Bolt Head Size (in)	N/A
Outboard Bolt Head Size (mm)	N/A
Outboard Bolt Head Type	N/A
Outboard Bolt Length (in)	N/A
Outboard Bolt Length (mm)	N/A
Outboard Joint Bolt Thread Size	N/A
Outboard Joint Type	Audi Style Spline Bolt
Outboard Shaft Connection Style	Audi Style Spline Bolt
Overall Compressed Length (in)	31.3
Overall Compressed Length (mm)	795
Grade Type	Premium
Inboard Joint Boot Material	Neoprene
Outboard Joint Boot Material	Neoprene
