Product Description

CORELESS VALVE

Features & Benefits

  • A highly reliable reservoir-mounted trailer valve that meets OE standards
  • Designed to control up to four spring brake actuators during parking or emergency applications
  • Automatically applies trailer spring brakes and protects trailer reservoir air pressure whenever there's a breakaway or trailer supply line failure
  • Applies and releases the trailer spring brakes repeatedly with a failed trailer reservoir(s)
  • Has optional anti-compounding feature to prevent an overriding service brake signal when the trailer supply line is at atmospheric pressure
  • Prevents service system charging when the parking brake circuit fails
  • Bendix SR-5 valves have one 1/2" or 3/4" NPT reservoir mounting port, one 1/4"-18 supply port, one 1/4"-18 service port, four 3/8"-18 delivery ports, two 1/4"-18 service reservoir ports, and a diaphragm-protected exhaust port
  • All Bendix valves help save on maintenance and repair costs and reduce downtime

Courtesy of Bendix – All rights reserved

Bendix SR-5 Air Brake Spring Brake Modulating Valve

A part of Bendix's comprehensive range of coreless valves, the Bendix SR-5 air brake spring brake modulating valve is a genuine Bendix remanufactured valve, but it does not require the return of the old valve core. It goes through stringent remanufacturing processes to meet or exceed OEM specifications in form, fit, and function.

Product Attributes

Series SR-5™

Additional Information

Core Class 7A
Core Group 74
Country of Origin (Primary) MX
Harmonized Tariff Code (HTS) 8481200070
UPC 07894294760619
VMRS Code 013010104

Part Interchanges

A part of the Knorr-Bremse Group, Bendix® provides the automotive and truck parts industry with cutting-edge energy management solutions, active safety technologies, and air brake charging for tractors, buses, commercial vehicles, trailers, as well as medium- and heavy-duty trucks throughout North America. Headquartered in Elyria, Ohio, Bendix Commercial Vehicle Systems employs over 3,200 people who work hand in hand for the accomplishment of the brand's vision: "to become the leading worldwide supplier of active vehicle safety systems within the commercial vehicle industry." This brand takes pride in being the first to introduce many notable parts and technologies to the North American commercial vehicle market. Among these many firsts are the groundbreaking air brake system technologies such as air dryers, air compressors, and ABS. At Bendix, exceeding industry standards is a strict requirement.

BENDIX OR109617 Cross Reference

We have 2 alternatives for the OR109617 by BENDIX:
