APSCO part description

CYL 4 X 24 DA 16 BR PK

Product Attributes

Series Highlift
Bore Diameter 4 in.
Stroke Length 24 in.
Cylinder Type Tie Rod, Twin, Double Acting
Pin Kit Included Yes
Seal Kit Part No. SK-3909
Force Rating 1257 LB Force at 100 PSI
Push Rod Thread Diameter 1"-14
Port Diameter 3/8 in. NPT
Port Quantity 2
Mounting Type Bracket End
Bracket Length 16 in.

APSCO® is a proud manufacturer of pneumatic cylinders, controls, and valves for the mobile, truck equipment, and automotive industries since 1964. The company continuously evolves to meet industry challenges and the changing needs of customers. But providing innovative solutions need not compromise quality, and that's APSCO's commitment since day one. The company makes use of the highest quality materials and the latest technology in manufacturing its products. And it rigorously tests them before shipment to ensure only safe and reliable APSCO products reach their customers. These stringent manufacturing processes and tests have earned them an ISO 9001:2001-certified company, beginning in 2004.
