PETERSON LIGHTING part description

826C-7/824C-7 LumenX® 4" Round LED Back-Up Light, PL3

Features & Benefits

  • 7-diodes, 4" round clear LED back-up light
  • Advanced optics fully illuminate lens
  • A single light meets FMVSS 108 requirements when properly mounted
  • Industry-standard PL3 socket integrated into housing
  • 824-7 has flange integrated into the housing
  • 826-7 has skirted weld joint for added protection against moisture
  • 9–16 volt operating range
  • Regulated design provides voltage protection and consistent light output over entire voltage range
  • Does not require “Top” positioning to meet FMVSS 108 standard
  • 826 kit includes light, grommet and 431-49 plug.
  • 824 kit includes light and 431-49 plug

Product Description

LED BACK-UP LIGHT, ROUND, GROMMET-MOUNT, 4"

Features & Benefits

  • 7 diodes.
  • Available in retail-friendly Viz Pack.
  • Lumenx® lens and circuitry.
  • Made in USA.
  • Voltage Regulated.
  • Advanced optics fully illuminate lens.
  • A single light meets FMVSS 108 requirements when properly mounted.
  • Industry-standard PL3 socket integrated into housing.
  • 824-7 has flange integrated into the housing.
  • 826-7 has skirted weld joint for added protection against moisture.
  • 9–16 volt operating range.
  • Regulated design provides voltage protection and consistent light output over a wide voltage range.
  • Does not require “Top” positioning to meet FMVSS 108 standard.
  • 826 kit includes light, grommet and 431-49 plug.
  • 824 kit includes light and 431-49 plug.

426-18: grommet (poly pack - std qty 12)

Product Attributes

Bulb Technology LED
Bulb/diode Count 7
California Proposition 65 Required Y
Container Type poly bag
Diameter 4.25 IN
Family LumenX
Height 4.25 in
Length 4.25 in
Lens Color clear
Light Color white
Marine Use Y
Maximum Voltage 16 Volts
Minimum Voltage 9 Volts
Mounting Type grommet
Multi-volt N
Regulatory Compliance DOT
Shape round
Termination PL3
Voltage 12 Volts
Width 1.62 in

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8512204000
UPC 00044464993904
VMRS Code 034003142

Part Interchanges

PETERSON LIGHTING 826C-7 Cross Reference

We have 1 alternatives for the 826C-7 by PETERSON LIGHTING:

Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
