(888) 312-8812 Login SignupDANA SPICER 5-3212X Axle Shaft Universal Joint Non-Greaseable; AAM1555WJ Series
Tap to view 5 more
$10249
Limited availability at this price!
In Stock
Get it by Wednesday, Aug 19
DANA SPICER 5-3212X Part Description
Manufacturer
Product Description
Axle Shaft Universal Joint Non-Greaseable; AAM1555WJ Series
Features & Benefits
- Journal cross is engineered with a solid cold-formed body to ensure better wear and overall strength.
- Bearing cups are heat treated for strength; precision-ground and case-hardened for durability.
- Multi-lip seal keeps grease in and contaminants out, and gets maximum retention in a wider range of environments.
- Thrust washers eliminate metal-to-metal contact, prevent wear and lower the overall operating temperature.
5-3212X Dana Spicer 1555 Series Front Axle U Joint Dodge AAM 9.25" 2500/3500
74081555, 68004853AB -- THIS U-JOINT IS DESIGNED FOR USE IN THE FRONT AXLE ASSEMBLY ONLY, NOT FOR THE DRIVESHAFT.
Please use the online catalog to select your part numbers
D1 BEARING CAP DIA:
D2 BEARING CAP DIA:
K1 SNAP RING DIM:
K2 SNAP RING DIM:
OEM MFG:AAM
OEM SERIES:1555WJ
74081555, 68004853AB -- THIS U-JOINT IS DESIGNED FOR USE IN THE FRONT AXLE ASSEMBLY ONLY, NOT FOR THE DRIVESHAFT.
Please use the online catalog to select your part numbers
D1 BEARING CAP DIA:
D2 BEARING CAP DIA:
K1 SNAP RING DIM:
K2 SNAP RING DIM:
OEM MFG:AAM
OEM SERIES:1555WJ
DANA SPICER 5-3212X Specifications
Product Attributes
| Material | Steel |
| Bearing Cap Diameter (1) | 1.375 IN |
| OEM Mfg | AAM |
| OEM Series | AAM 1555WJ |
| Type | ISR Style |
| Bearing Cap Diameter (2) | 1.375 IN |
| Bearing Cap Type | Round with ISR Groove |
| Snap Ring Included | Yes |
| Snap Ring Type | Internal |
| Grease Zerk Included | Not Required |
| Pre Greased | Yes |
| Greaseable | No |
| Bearing Cap Diameter A (mm) | 34.925 MM |
| Bearing Cap Diameter B (mm) | 34.925 MM |
| Bearing Cap Type A | ISR |
| Bearing Cap Type B | ISR |
| Hardware Included | No |
| Length A (In) | 3.737 IN |
| Length A (mm) | 94.742 MM |
| Length B (In) | 3.737 IN |
| Length B (mm) | 94.742 MM |
| Mounting Hardware Included | No |
| Distance Btw Snap Ring Grooves | 3.737 |
| Distance Btw Snap Ring Grooves (ISR) (2) | 3.737 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8708996810 |
| UPC | 00023913254308 |
| VMRS Code | 024002046 |
DANA SPICER 5-3212X Cross References
| Brand | Part Number |
|---|---|
| SP53212X, W718093SS3JS | |
| American Axle & Manufacturing | 74081555 |
| Chrysler | 6806 5428AA, 6806 5428AB, 6806 5428AC, 68065428AA, 68065428AB, 68065428AC, 6806 5428AD, 68065428AD |
| DANA | 25-3212X |
| GMB | 210-1557 |
| MOOG Chassis Products | 479 |
| MasterPro | 479 |
| NEAPCO | 3-1557 |
| Navistar | DS53212X |
| Neapco OE Series | 31557, 3-1557 |
| Precision | 479 |
| SKF | 3-1557, UJ479 |
DANA SPICER 5-3212X Fits Vehicles
- Dodge Ram 2500 (2010)
- Ram 5500 (2011-2018)
- Ram 4500 (2011-2018)
- Dodge Ram 5500 (2008-2010)
- Ram 3500 (2011-2024)
- Ram 2500 (2011-2024)
- Dodge Ram 3500 (2010)
- Dodge Ram 4500 (2008-2010)
DANA SPICER 5-3212X Customer Reviews
No reviews yet
Be the first to review this product!
DANA SPICER 5-3212X Manufacturer Information
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
