PETERSON LIGHTING part description

820A-10/823A-10 LumenX® Oval LED Front and Rear Turn Signal, AMP

Peterson Lighting LumenX® Oval LED Front and Rear Turn Signal

The Peterson Lighting LumenX® oval LED front and rear turn signal is designed to let other truckers and road users know where your truck wants to go. It is also effective at adding a unique and striking look to your rig.

Features & Benefits

  • A 10-diode oval LED front and rear turn signal light that’s built to offer years of reliable service
  • Comes with an AMP-compatible connector that is integrated into the housing to form a single unit
  • Designed to meet DOT standards for side marker use and both front and rear turn signal requirements
  • Has both low intensity marker light and turn signal light circuits
  • With fully illuminated lens because of its new white diodes behind amber lens and advanced optics
  • Operating range is 9 to 32 volts and is made compatible with 12V & 24V systems
  • Provides voltage protection and consistent light output over entire voltage range with its regulated design
  • Must be in in horizontal, vertical, or any 360-degree position to meet FMVSS 108 standards
  • Available as a kit that includes light, plug, and grommet
  • Made of durable components to withstand a lot of external pressure

Product Description

LED TURN SIGNAL, FRONT & REAR OVAL, AMP, GROMMET-MOUNT KIT 6.5"X2.25" MV

Features & Benefits

  • 11 diodes.
  • Defender harness & lighting system approved.
  • Lumenx® lens and circuitry.
  • Made in USA.
  • Multivolt version available.
  • Voltage Regulated.
  • Meets DOT standards for both FRONT and REAR turn signal use.
  • White diodes behind amber lens.
  • Advanced optics fully illuminate lens.
  • Includes both turn signal and low intensity marker light circuits.
  • Meets DOT side marker requirements.
  • AMP-compatible connector integrated into housing.
  • Regulated design provides voltage protection and consistent light output over a wide voltage range.
  • 823-10 has flange welded to light, forming a single unit.
  • 9-32 volt operating range compatible with both 12V and 24V vehicles.
  • Meets FMVSS 108 req. in horizontal, vertical or any 360° position.
  • 820 kit includes light, grommet and 817-49 plug.
  • 823 kit includes light and 817-49 plug.

421-18: grommet (poly pack - std qty 12)

Product Attributes

Length 6.5 IN
Bulb Technology LED
Bulb/diode Count 10
California Proposition 65 Required Y
Container Type poly bag
Family LumenX
Height 2.31 in
Integral Reflex N
Lens Color amber
Light Color amber
Marine Use Y
Maximum Voltage 32 Volts
Minimum Voltage 9 Volts
Mounting Type grommet
Multi-volt Y
Regulatory Compliance DOT
Shape oval
Termination AMP
Voltage 12 Volts
Width 1.45 in

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8512204000
UPC 00044464993744
VMRS Code 034003191

Part Interchanges

Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
