*Representative image - actual part not displayed
Centric 123.42018 - C-Tek Standard Brake Drum
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 6.818 |
| Weight [cntrc] Lbs | 15.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 68.000 |
| Hub Hole / Register [cntrc] In | 2.677 |
| Height [cntrc] Mm | 73.000 |
| Height [cntrc] In | 2.874 |
| Friction Surface Width [cntrc] Mm | 58.170 |
| Friction Surface Width [cntrc] In | 2.290 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 261.000 MM |
| Maximum Brake Diameter (Discard) | 10.276 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 297.000 MM |
| Outside Diameter | 11.693 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.500 MM |
| Mounting Hole Diameter | 0.492 IN |
| Nominal Drum Diameter | 260.000 MM |
| Nominal Drum Diameter | 10.236 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890914648 |
Part Interchanges
CENTRIC 123.42018 Cross Reference
We have 2 alternatives for the 123.42018 by CENTRIC:
Fits Vehicles
- Nissan Stanza (1986)
