GATES 70291 Global G2L PolarFlex Hose - SAE 100R2 Type S

Name: Gates 70291 Global G2L PolarFlex Hose - SAE 100R2 Type S
SKU: 70291
Price: 12.15 USD
Availability: OutOfStock

$12.15

MSRP Pricing shown.

Out of Stock

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

GATES 70291 Part Description

Global G2L PolarFlex Hose - SAE 100R2 Type S

For use with Field Attachable Type T Couplings [G28 Series], GlobalSpiral Couplings [G20 Series], GlobalSpiral Plus Couplings [G22 Series] and MegaCrimp Couplings [G25 Series]
Tested to industry-standard 600,000 impulse cycles
Unique low temperature tube for extended service life at extremely low temperatures
Meets Flame Resistance Acceptance Designation MSHA 2G
Temperature Range: -70 Deg. F to +212 Deg. F (-57 Deg. C to +100 Deg. C)

Product Type	Global G2L PolarFlex Hose - SAE 100R2 Type S
Industrial Description	10G2LXREEL
Type	Hydraulic Hose
Hose Pressure Description	High Pressure
Maximum Working Pressure	3625 PS
Burst Pressure	14500 PS
Temperature Rating	-70 Deg. F to +212 Deg. F (-57 Deg. C to +100 Deg. C)
Length	220 FT
Dash Size	10
Inside Diameter	.625 IN
Outside Diameter	.99 IN
Bend Radius	8 IN
Tube Description	Black, Oil-Resistant, Synthetic Rubber
Hose Material	Nitrile - Type C
Reinforcement Material	Two Braids, High-Tensile Steel Wire
Cover Material	Thin Synthetic Rubber - Chloroprene - Type A
Cover Type	Type A - Flame, Oil & Abrasion Resistant
Cover Color	Black
Coupling Recommendation	GlobalSprial, MegaCrimp
SAE Standard	100R2
EN Standard	853 2SN
ISO Standard	1436 2SN R2

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	4009210000
Stock Status	N
UPC	00072053470772
VMRS Code	059032029
UNSPSC	40142020
