WABCO 9347141250 - WN9347141250
$1,29999
Limited Availability
. Learn more
WABCO part description
Product Attributes
| Port thread 1 | 1/2" - 14 Dry Seal PTF |
| Max. operating pressure | 188.5 psi |
| Charging Pressure | 3.75 bar |
| Calculated Volume (dm³) | 0.8514 |
| Size | 110 x 90 x 86 |
| Port thread 4 | 3/8" - 18 Dryseal PTF |
| Port thread 23 | 3/8" - 18 Dry Seal PTF |
| Port thread 21 | 3/8" - 18 DRYSEAL NPTF |
| Port thread 22 | 3/8" - 18 Dry Seal PTF |
| Closing Pressure Dynamic 24 | 72.5 psi |
| Opening pressure 21 | 7 bar |
| Opening pressure 22 | 7 bar |
| Closing Pressure Dynamic 21 | 72.5 psi |
| Closing Pressure Dynamic 23 | 72.5 psi |
| Opening Pressure Circuit 1+2 | 6.2 + 6.2 bar |
| Weight | 1.4947 |
| Opening pressure 23 | 7.5 bar |
| Type | dynamic |
| Port thread 24 | M16 x 1.5 |
| Pressure Sensor | No |
| Opening pressure 24 | 7 bar |
| Closing Pressure Dynamic 22 | 72.5 psi |
| Temperature Range | -40°C to +90°C |
WABCO 9347141250 Cross Reference
We have 5 alternatives for the 9347141250 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
