Centric 130.33109 - Centric Premium Brake Master Cylinder
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
Product Attributes
| Publication Bore [cntrc] | 25mm |
| Primary Outlet Flare Type [cntrc] | Bubble |
| Product Grade [cntrc] | Premium |
| Boss, Nipple Or Port: Rear, Right: #a [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | M10-1.00 bbl |
| Push Rod: Length / Depth [cntrc] In | 1.96 |
| Secondary Outlet Flare Type [cntrc] | Bubble |
| Boss, Nipple Or Port: Bottom [cntrc] | M10-1.00 bbl |
| Weight [cntrc] Lbs | 3.1 |
| Weight [cntrc] Kgs | 1.41 |
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 25.000 MM |
| Master Cylinder Bore Diameter | 0.984 IN |
| Brake Booster Included | No |
| Master Cylinder Cap Included | No |
| Master Cylinder Material | Cast Iron |
| Push Rod Included | No |
| Reservoir Included | No |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 10.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 3 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.00 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Straight |
| Bore Size | 25.000 MM |
| Bore Size | 0.984 IN |
| Secondary Outlet Thread Size | M10-1.00 |
| Primary Outlet Thread Size | M10-1.00 |
| Primary Outlet Flare Type | Bubble |
| Secondary Outlet Flare Type | Bubble |
| Primary Bore Diameter | 25.000 MM |
| Primary Bore Diameter | 0.984 IN |
| Reservoir Style | Removable |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | DE |
| Harmonized Tariff Code (HTS) | 8413919050 |
| UPC | 805890000556 |
Part Interchanges
CENTRIC 130.33109 Cross Reference
We have 3 alternatives for the 130.33109 by CENTRIC:
Fits Vehicles
- Audi 5000 Quattro (1986-1988)
- Audi 200 (1989-1991)
- Audi 100 (1989)
