Name: Reach Cooling 42-10734 Radiator
SKU: 4210734
Price: 281.99 USD
Availability: InStock

REACH COOLING part description

Radiator

Product Description

Radiator

Features & Benefits

Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Folded fin edges increase stability and heat disbursement properties.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.

Product Attributes

Core Height	23 1/4 IN
Outlet Header Length	22 3/8 IN
Core Material	Aluminum
Inlet Diameter	38.1 MM
Outlet Diameter	1.5 IN
Outlet Diameter	38.1 MM
Core Thickness	36 MM
Outlet Location	Lower Left
Tank Material	Plastic
Outlet Header Width	2.25 IN
Core Height	590.6 MM
Core Width	548 MM
Inlet Location	Upper Left
Outlet Diameter	38 MM
Outlet Header Width	56.90 MM
Frame Included	Yes
Engine Oil Cooler Included	No
Core Height	590.55 MM
Core Thickness	36.499 MM
Outlet Header Length	568.325 mm
Inlet Header Width	57.2 MM
Down Flow Or Cross Flow Type	Down Flow
Core Thickness	1.437 IN
Inlet Header Length	568.3 MM
Inlet Header Width	2 1/4 IN
Inlet Diameter	38.1 mm
Inlet Header Length	568.325 mm
Inlet Header Length	22 3/8 IN
Outlet Header Length	568.3 MM
Inlet Diameter	1 1/2 IN
Radiator Cap Included	No
Core Width	547.674 MM
Inlet Header Width	57.15 mm
Outlet Header Width	57.15 mm
Core Width	21.562 IN
Transmission Oil Cooler Included	No

Part Interchanges

Fits Vehicles

Isuzu NQR (1999-2004)
Isuzu NPR (1999-2004)
GMC W5500 Forward (2000-2004)
GMC W4500 Forward (1999-2004)
GMC W3500 Forward (1999-2004)
Chevrolet W5500 Tiltmaster (2000-2004)
Chevrolet W4500 Tiltmaster (1999-2004)
Chevrolet W3500 Tiltmaster (1999-2004)
