Name: Reach Cooling 42-10647 Radiator
SKU: 4210647
Price: 1271.99 USD
Availability: InStock

REACH COOLING part description

Radiator

Product Description

Radiator

Application Summary

2012-2016 Freightliner Cascadia; 2012-2014 Freightliner M2 112

Features & Benefits

Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Our fin edges are folded for increased stability and heat disbursement properties.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
Folded fin edges increase stability and heat disbursement properties.
Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.

No Shipping Restriction

radiator, complete, industrial, heavy duty, engine cooling, rad, cooling

Product Attributes

Tank Material	Plastic
Core Thickness	2 3/16 IN
Core Material	Aluminum
Inlet Diameter	2 1/2 IN
Core Height	35 11/16 IN
Outlet Diameter	2.5 IN
Frame Included	No
Core Width	38 1/2 IN
Core Height	906.449 MM
Engine Oil Cooler Included	No
Core Width	977.9 MM
Core Width	977.9 MM
Down Flow Or Cross Flow Type	Down Flow
Core Thickness	55.549 MM
Outlet Location	Bottom Left
Inlet Diameter	63.5 mm
Outlet Diameter	64 MM
Inlet Diameter	63.5 MM
Core Thickness	55.6 MM
Outlet Diameter	63.5 MM
Core Height	906.5 MM
Inlet Location	Top Right
Radiator Cap Included	No
Transmission Oil Cooler Included	No

Additional Information

Warranty Special UOM	TX
Country of Origin (Primary)	CA
Remanufactured Part	N
Harmonized Tariff Code (HTS)	8708915000
Warranty Time UOM	MO
Harmonized Tariff Code (Schedule B)	8708915000
Warranty Time	12
Stock Status	N
UPC	06941099926229
VMRS Code	042002001
UNSPSC	25174002

Part Interchanges

Fits Vehicles

Freightliner Cascadia (2012-2016)
Freightliner M2 112 (2012-2014)
