*Representative image - actual part not displayed
Centric 120.66083 - Centric Premium Brake Rotor
$17549
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 44.750 |
| Disc Mounting [cntrc] | Floating / DIH |
| Hat Id [cntrc] Mm | 221.600 |
| OEM Vane Count [cntrc] | 47 |
| Vane Style [cntrc] | Straight |
| Hat Id [cntrc] In | 8.724 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 20.300 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.516 IN |
| Discard Thickness | 38.500 MM |
| Nominal Thickness | 1.575 IN |
| Nominal Thickness | 40.000 MM |
| Hat Finish | Coated |
| Overall Height | 150.000 MM |
| Overall Height | 5.906 IN |
| Outside Diameter | 355.000 MM |
| Outside Diameter | 13.976 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 226.800 MM |
| Nominal Drum Diameter | 8.929 IN |
| Bearings Included | No |
| Center Hole Diameter | 144.000 MM |
| Center Hole Diameter | 5.669 IN |
| Mounting Bolt Hole Circle Diameter | 7.087 IN |
| Mounting Bolt Hole Circle Diameter | 180.000 MM |
| Stud/Lug Hole Quantity | 8 |
| Stud/Lug Hole Diameter | 0.634 IN |
| Stud/Lug Hole Diameter | 16.100 MM |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590539554 |
Part Interchanges
CENTRIC 120.66083 Cross Reference
We have 2 alternatives for the 120.66083 by CENTRIC:
Fits Vehicles
- Chevrolet Silverado 3500 HD (2020-2024)
- GMC Sierra 3500 HD (2020-2024)
