MAIN FILTER part description

Technical Specifications

Outside Diameter Top 4.488
Outside Diameter Bottom 4.488
Inside Diameter Bottom 2.697
BPVS Setting PSI 44
Collapse Pressure 435
Operating Temp Min F -13
Operating Temp Max F 248
Capacity gr 274.120786
Filter Area sq in 3053
Flow Direction Outside-In
Gasket Material Viton
Fluid Type HH / HL / HM / HV
Beta Ratio 1 200/20.7
Beta Ratio 2 1000/26.6
Micron 1 25

Features & Benefits

  • Interchange/replacement for OEM INTERNORMEN p/n 021700R20VG30HCSP
  • Compatible with OEM filter in fit, form and function
  • All of our elements are manufactured following ISO specifications.
  • Buy hydraulic filters direct from the manufacturer
  • Built using Quality Components with strict quality control.
  • Main Filter MF0429018 replaces OEM 021700R20VG30HCSP by INTERNORMEN and is compatible in fit, form and function.
  • All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
  • Images may be a general representations of products
  • Images may be a general representations of products

Features & Benefits

  • Interchange/replacement for OEM INTERNORMEN p/n 021700R20VG30HCSP
  • Compatible with OEM filter in fit, form and function
  • All of our elements are manufactured following ISO specifications.
  • Buy hydraulic filters direct from the manufacturer
  • Built using Quality Components with strict quality control.
  • Main Filter MF0429018 replaces OEM 021700R20VG30HCSP by INTERNORMEN and is compatible in fit, form and function.
  • All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
  • All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
  • Images may be a general representations of products

Product Attributes

Handle Yes
Wrap Yes
Micron Rating 20
Outside Diameter (Top) 4.49 in.
Minimum Operating Temperature -13 Deg Fahrenheit
Filter Area (sq. in.) 3053
Flow Direction Outside-In
Gasket Material Viton
Height (in.) 31.18
Beta Ratio 2 1000/26.6
Bypass Yes
BPVS Setting (PSI) 43.5
Maximum Operating Temperature 248 Deg Fahrenheit
Product Media Glass
Collapse Pressure 435
Fluid Type HH / HL / HM / HV
Beta Ratio 1 200/20.7
Dust Holding Capacity 274.12 grams
