WABCO 9253920380 - Air Brake Spring Brake Actuator - Tristop Series, Double Diaphragm, 30/30
$11349
30 day lead time
Pay over 3-12 months with
. Learn more
. Learn more
WABCO part description
Double-Diaphragm Tristop, 30/30
Product Attributes
| Max. operating pressure | 10.0 bar |
| Distance between bolts | 120.6 mm |
| Weight | 20.83 |
| Port Angle | 0° |
| Push-Rod Length | 254 mm |
| Type | 30/30 |
| Port thread 12 | 3/8" - 18 NPTF |
| Calculated Volume (dm³) | 23.8 |
| Release Pressure | 4.6 bar |
| Size | 450 x 230 x 230 |
| Temperature Range | -40°C to +80°C |
| Port thread 11 | 3/8" - 18 NPTF |
| Stroke | 64.0 mm |
| Bolt Lengths | 38.0 mm |
| Type Of Operation | Cam |
| Push-rod thread | 5/8'' - 18 UNF |
| Version | Without boot |
| Yoke | Without |
| Total Length | 340.0 mm |
| Bolt Threads | 5/8'' - 11 UNC |
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
