ACDelco 18A2342AC - Disc Brake Rotor - 5 Lug Holes, Cast Iron, Coated, Plain Vented, Front
$7049
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
ACDELCO part description
Silver™ Disc Brake Rotor - Front, Vented
Product Description
Front Brake Rotor
Product Attributes
| Nominal Thickness | 28.194mm (1.11 in.) |
| Center Hole Diameter | 73.66mm (2.9 in.) |
| BOLT CIRCLE | 115.011mm (4.528 in.) |
| Lug Holes Quantity | 5 |
| Lug Holes Quantity | 5 |
| Minimum Thickness | 26.492mm (1.043 in.) |
| Minimum Thickness | 26.492mm (1.043 in.) |
| Quantity | 1 Per Pack |
| Quantity | 1 Per Pack |
| Rotor Construction | 1-Piece |
| Rotor Construction | 1-Piece |
| Rotor Design | Rotors Only |
| Rotor Design | Rotors Only |
| Rotor Diameter | 320mm (12.6 in.) |
| Rotor Diameter | 320mm (12.6 in.) |
| Rotor Finish | Coated |
| Rotor Finish | Coated |
| Rotor Height | 55.88mm (2.2 in.) |
| Rotor Height | 55.88mm (2.2 in.) |
| Rotor Material | Cast Iron |
| Rotor Material | Cast Iron |
| Rotor Style | Plain |
| Rotor Style | Plain |
| Rotor type | Vented |
| Rotor type | Vented |
| Rotor Vane Type | Non-Directional |
| Rotor Vane Type | Non-Directional |
| Discard Thickness | 26.5 MM |
| Mounting Bolt Hole Diameter | 0.667 IN |
| Height (in) | 2.2 in |
| Width (in) | 2.8 in |
| Center Bore Diameter (in) | 2.9in |
| Bolt Circle Diameter (in) | 4.5 in |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 12.598 IN |
| Length (In) | 13.5 IN |
| Weight | 20.7 lb |
| Discard Thickness | 1.043 IN |
| Mounting Bolt Hole Diameter | 16.95 MM |
| Height (mm) | 55.9 mm |
| Center Bore Diameter (mm) | 73.7mm |
| Bolt Circle Diameter (mm) | 114.3 mm |
| Mounting Bolt Hole Circle Diameter | 4.528 IN |
| Product Description | ACDelco Advantage Coated Disc Brake Rotors provide reliable vehicle braking power. Their robotic-applied, baked-on coating helps prevent brake pulsation, helps prevent the rotor from seizing to the hub, and provides superior rust prevention against harsh environmental elements such as rain, snow, and corrosive road sprays. They feature a non-directional ground finish that helps to extend brake pad life and minimizes thickness variation. They are also ready to be installed right out of the box, with no machining required. These dependable aftermarket Advantage Coated Disc Brake Rotors offer quality at an economical price. ⚠<b> WARNING:</b> Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Material | Cast Iron |
| FAQ - Question 1 | Does ACDelco offer other grades of brake rotors? |
| Construction | Full Cast |
| Features & Benefits - Bullet 1 | Manufactured with multiple alloys for improved heat dissipation and performance |
| Features & Benefits - Bullet 2 | Mill-balanced for proper rotor function; no extra weights needed |
| Slotted | No |
| Programming Required | No |
| Disc Finish | Non Directional |
| Hat Finish | Plain |
| Features & Benefits - Bullet 3 | Quality validated for proper metallurgy and correct brake plate thickness |
| Grade Type | Regular |
| Features & Benefits - Bullet 4 | Rounded radius for added strength |
| Surface Type | Smooth |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 4 | Vehicle pulls to the left or right when brakes are applied. |
| Solid Or Vented Type Rotor | Vented |
| Signs of Wear & Troubleshooting - Section 1 - Bullet 5 | Visible ridges or deep grooves on the rotor surface. |
| Rust Resistant Coating | Yes |
| FAQ - Answer 1 | Yes, ACDelco also offers GM OE brake rotors and Professional brake rotors. |
| Mounting Bolt Hole Circle Diameter | 115 MM |
| Directional or Non-Directional Brake Surface | No |
| Center Hole Diameter | 72.65 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Center Hole Diameter | 2.86 IN |
| Outside Diameter | 320 MM |
| Overall Height | 54.6 MM |
| Stud/Lug Hole Quantity | 5 |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Overall Height | 2.15 IN |
| ABS Tone Ring Included | No |
Additional Information
| Warranty Special | 12 Months/Unlimited Miles Limited Warranty (Parts Only). Please see ACDelco.com for more details|12 Months/20,000 Kilometers Limited Warranty (Parts Only). Please see ACDelcocanada.com for more details |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Country of Origin (Primary) | CN |
| Warranty Special UOM | TX |
| UPC | 00808709339496 |
Fits Vehicles
- Dodge Challenger (2009-2023)
- Dodge Magnum (2005-2008)
- Dodge Charger (2006-2023)
- Chrysler 300 (2005-2023)
