EUCLID part description

Collar Diameter 1.21 in.
Collar Length 0.31 in.
Collar Style Round
Grade 8
Hub End Body Diameter 0.975 in.
Hub End Length 1.88 in.
Hub End Thread 7/8/2014
Hub End Thread Length 0.93 in.
Length 5 5/8 in.
Serration Serrated
Serration Diameter 1.006 in.
Serration Length 0.44 in.
Type Shoulder
VMRS Code 018-003-009
Wheel End Body Diameter 1.161 in.
Wheel End Length 3.78 in.
Wheel End Length to First Thread 2.25 in.
Wheel End Thread 7/8/2014
Wheel End Thread Length 1.53 in.
Wheel End Threads per Inch 14

Product Description

STUD

Product Attributes

Brand Euclid
Collar Diameter 1.21 in.
Collar Length 0.31 in.
Collar Style Round
Grade 8
Hub End Body Diameter 0.975 in.
Hub End Length 1.88 in.
Hub End Thread 7/8"-14
Hub End Thread Length 0.93 in.
Length 5 5/8 in.
Pallet Quantity 300
Serration Serrated
Serration Diameter 1.006 in.
Serration Length 0.44 in.
Type Shoulder
Weight 1.14
Wheel End Body Diameter 1.161 in.
Wheel End Length 3.78 in.
Wheel End Length To First Thread 2.25 in.
Wheel End Thread 7/8"-14
Wheel End Thread Length 1.53 in.
Wheel End Threads Per Inch 14

EUCLID E-9007 Cross Reference

We have 3 alternatives for the E-9007 by EUCLID:

Euclid® is a world leader in the production of precision-engineered replacement parts for buses, trailers, as well as light-, medium- and heavy-duty trucks. This brand takes great pride in its products that meet and even exceed O.E.M. quality standards. Officially a part of Meritor since January 1999, Euclid remains the same despite all the changes the company has been through. When customers receive Euclid products, they know they are getting far more than ordinary replacement parts. Instead, they are getting the best replacement parts made today from a company they can trust. Euclid is a company that's continuously improving with technology to do a job the right way because it is the only way it knows how.
