PETERSON LIGHTING part description

253 LED Clearance/Side Marker with Aux. Function

Peterson Lighting LED Clearance/Side Marker with Auxiliary Function

The Peterson Lighting LED clearance/side marker with auxiliary function offers improved trucking safety as it alerts other road users of your vehicle’s location, position, and dimension in poor visibility situations. It is also a perfect way to add a unique style to your rig while keeping it safe on the road.

Features & Benefits

  • A 3-diode rectangular LED light that works as a clearance light, side marker light, and an ID light
  • Must be mounted horizontally with up to a 32° tilt back to meet DOT requirements
  • Designed with a third wire so that it can perform an auxiliary brake or turn function
  • With lens that is welded to the housing to form a single, rugged unit
  • Has a hardwired design to prevent lamp-plug features and stripped leads with ring terminal on ground
  • With 9- to 16-volt operating range
  • Manufactured to meet the highest quality and safety standards

Product Description

LED MARKER/CLEARANCE, P2, RECTANGULAR, W/AUXILIARY FUNCTION, 2.5"X1.21"

Features & Benefits

  • 3 diodes.
  • Hardwired design.
  • Rectangular LED clearance, side marker and ID light.
  • Features a third wire for auxiliary brake or turn functions.
  • DOT legal when mounted horizontally with up to a 32° tilt back.
  • Hardwired design has stripped leads with ring terminal on ground.
  • 9-16 voltage operating range.
  • See mounting accessories on Peterson Master Catalog pages 175–176 for additional mounting options.

150-095: surface-mount bracket (poly pack - std qty 12)

Product Attributes

Lens Color amber
Shape rectangular
Bulb Technology LED
Bulb/diode Count 1
California Proposition 65 Required Y
Container Type bulk pack
Diameter 2.5 IN
Family PM
Height 1.21 in
Integral Reflex N
Length 2.5 in
Light Color amber
Marine Use Y
Maximum Voltage 16 Volts
Minimum Voltage 9 Volts
Mounting Type grommet
Multi-volt N
Pc Rated N
Regulatory Compliance DOT
Termination stripped wire
Voltage 9 Volts
Width 0.84 in

Additional Information

Country of Origin (Primary) TW
Harmonized Tariff Code (Schedule B) 8512202000
UPC 00044464990804
VMRS Code 034004253

PETERSON LIGHTING M253A Cross Reference

We have 1 alternatives for the M253A by PETERSON LIGHTING:

Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
