MONROE part description

Specifications
  • Upper Mounting Code :Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch
  • Lower Mounting Code :Loop Bushing& Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL
  • Compressed Length :10.000"
  • Extended Length :14.750"
  • Travel Length :4.750"
  • Dust Shield :Yes
  • Parts Pack(s) :P1135
  • Compressed Bumper Stop :No
  • Extended Bumper Stop :Yes
  • Extended Hydraulic Lockout :No
  • Compressed Hydraulic Lockout :No
  • Dust Shield Material :Metal
Feature and Benefit
  • The Monroe Reflex truck shock absorber with the patented ASD Technology combines specially tuned valving with a Fluon banded piston. The ASD valve has the ability to sense acceleration to improve the handling, safety, and overall ride characteristics of sport-utility vehicles, mini-vans and light trucks. The ASD base valve will sense a bump in the road and automatically adjust the shock to absorb the impact, leaving the shock with greater control when it is needed. The features of the Monroe Reflex truck shock absorber make it the superior shock for improved handling, safety, and comfort in all road conditions.
  • ASD Technology: Innovative valving provides greater control for handling, while improving ride comfort.
  • All Weather Fluid: Contains special modifiers to reduce friction and ensure smooth rod reaction.
  • Fluon Banded Piston: The fluon band provides consistent sealing between the piston and pressure tube which delivers better control and increased durability.
  • Full Displaced Valving: Tuned specifically for each application, this valving automatically adjusts to road extremes to provide consistency and ride
  • Nitrogen Gas Charged: For improved ride and handling, helps maintain tire to road contact by reducing aeration.
  • 2-1/4" or 2" Diameter Reserve Tube: Allows more fluid carrying capacity for a cooler running unit.
  • 1-3/8" Bore: Lower operating pressure than standard 1" bore units
  • 5/8" Piston Rod: Heavy-duty nitrocarburized rod for long service life. On non-dust shield units only

Product Description

Monroe Reflex Light Truck Shock Absorber

Monroe Reflex Light Truck Shock Absorber

Product Attributes

Upper Mounting Code --- - Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch
Lower Mounting Code --- - Loop Bushing & Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL
Compressed Length --- - 10.000"
Extended Length --- - 14.750"
Travel Length --- - 4.750"
Dust Shield --- - 'Yes'
Parts Pack(s) --- - P1135
Compressed Bumper Stop --- - 'No'
Extended Bumper Stop --- - 'Yes'
Extended Hydraulic Lockout --- - 'No'
Dust Shield Material --- - Metal
Feature Point --- - ! 'Special Seal: ''Self-lubricating'' fluid seal designed to retain gas without excessive wear or friction.'

MONROE 911034 Cross Reference

We have 2 alternatives for the 911034 by MONROE:

Monroe products are built for the road ahead. Since its founding in 1916, Monroe® has been known for its world-class solutions that are precision-engineered and meticulously tested with the specific vehicle's ride and handling profile in mind. As the leading supplier of Original Equipment ride control products to global automotive manufacturers, Monroe helped establish the benchmarks of handling and ride excellence in every stage of a vehicle's life. Whether you're upgrading your truck, converting its suspension, or restoring its original state, Monroe has got you covered. It offers the best-in-class shocks, strut assemblies, steering stabilizers, conversion kits, lift support, and many other suspension components that will help enhance your safety and driving experience.
