MONROE part description

Product Description

OESpectrum Suspension Shock Absorber

Features & Benefits

  • EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
  • CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
  • BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
  • BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee

Product Attributes

9791 XP4
9789 S4
Dust Shield Included Yes
9783 No
9908 Yes
9792 No
Part Description Shock Absorber
Compressed Length 12.875 IN
Dust Shield Material Metal
Extended Length 20.375 in
Gas Charged Yes
Lower Mount Type Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.7/16" Pin Length (Hole Center to Center)
Parts Pack(s) P01136
Travel Length 7.5 in
Upper Mount Type Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598155160
VMRS Code 016008003
UNSPSC 25172011

Part Interchanges

Fits Vehicles

  • Jeep TJ (1997-2006)
  • Jeep Wrangler (1997-2006)
  • Jeep Wagoneer (1984-1990)
  • Jeep Comanche (1986-1990)
  • Jeep Cherokee (1984-1990)
