HORTON part description

Product Description

HT/S PolarExtreme Reman

Application Summary

FREIGHTLINER

Features & Benefits

  • State-of-the-art dust seal extends fan drive life
  • Premium Friction Liner for longer lasting performance
  • Patented System Sentry Fuse for advanced fan drive protection
  • Superior Hub Bearing provides extended line and moisture resistance
  • Rebuilt to the same as new

Replace with remanufactured fan drive 791009 or repair with appropriate repair kit.

Product Attributes

BACK PULLEY DIAMETER 5.88
BELT CONFIGURATION 2V
Belt Groove Location 3.36
BOLT CIRCLE 3.5
Fan Blade Stud Length 1.5 (.375-16)
FAN PILOT DIAMETER 1.99
Overall Length 8
VERTICAL MOUNTING DISTANCE 6.5

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8483604040
Harmonized Tariff Code (HTS) 8483604040
NAFTA Preference Criterion Code B
Warranty Distance 300000
Warranty Distance UOM DH
Warranty Special 2500 Hours
Warranty Special UOM TX
Warranty Time 36
Warranty Time UOM MO
VMRS Code 042003131

Part Interchanges

HORTON 791009 Cross Reference

We have 3 alternatives for the 791009 by HORTON:
