GROTE part description

Product Description

Solder Splice Terminal, 12

Features & Benefits

  • Color-coded tubing with wire gauge imprint provides easy identification of the correct part for the job
  • Completely insulates and protects electrical connections
  • Lead-free solder has greater surface tension
  • New solder sleeves are Tin & Bismuth alloy
  • Protects against added vibration in rugged environments
  • Protects splices from water, corrosion, salt and moisture, provides strain relief
  • RoHS compliant
  • better for the environment
  • Solder sleeves pre-fluxed to clean metals & provide a quality solder termination
  • Solder stays in place which provides greater tensile strength than other solder sleeves
  • UL listed

Product Attributes

Color Yellow
Connection Type Butt
Gauge 12-10 GA
Material Polyolefin
Prop 65 Label Required N
Rohs Yes
Functions Solder & Seal
Operating temperature -55 degree C (-67 degree F) to 110 degree C (230 degree F)
Shrink Ratio 3:1
Standards CSA-RU
Strength 2200 PSI

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8536900000
UPC 00621935024482
VMRS Code 053007002

GROTE 84-2612 Cross Reference

We have 2 alternatives for the 84-2612 by GROTE:
