GROTE part description

Product Description

3" SuperNova(R) LED Clearance Marker Lights, Amber

Features & Benefits

  • Uses the same UBS double-seal pigtail as the incandescent version for a quick Plug-and-Go(R) retrofit
  • Encapsulant potting for total circuit board protection
  • Hermetic lens-to-housing seal
  • Tin-plated, solid brass terminals are sealed to housing to resist corrosion and eliminate failure-causing leak paths

CLR/MKR LAMP - CLR/MKR LAMP, YELLOW, SUPERNOVA LED

Product Attributes

Amperage .06A
Color Amber
Connection Type PL-10
Functions P2
Housing Color White
LED Y
Lens Color Amber
Material Polycarbonate Housing,Polycarbonate Lens
Mounting Type Bracket,Grommet
Product Line - Trademark SuperNova(R)
Regulations FMVSS 108
Shape Rectangular
Size 3"
Voltage 12V

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8512200000
UPC 00089373451305
VMRS Code 034004253
