GROTE part description

Technical specifications

Material: Polycarbonate
Color: Yellow, Blue
Lens Color: Clear
Voltage: 12V
Amperage: 2.4A
Class: Class I
Gauge: 18 GA
Mounting Type: Permanent
Connection Type: Blunt Cut
Size: Low Profile, 17"
Height: 2.87"
Length: 6.32"
Standards: SAE J845

A low profile LED mini light bar that provides high performance warning and signaling benefit for a wide variety of special application needs. Permanent mount and magnet mount options available.

Features & Benefits

  • Includes 6" pigtail
  • Built-in electronic flasher with 30 Scan-Lock™ flash patterns
  • Low-profile light bar provides high performance characteristics of LED lighting in a small size
  • Six internal LED modules provide 360° light output
  • Permanent mount on 14 1/16" x 3 7/16" hole centers
  • Mounting hardware and instructions included
Color/Finish Yellow/Blue
Material Polycarbonate
Class I
Voltage 12V / 3A (peak) / 1.2A (avg)
Lighting Technology LED

GROTE 76770 Cross Reference

We have 1 alternatives for the 76770 by GROTE:

Established in 1901, Grote® is a world-class manufacturer and supplier of light components and smart visibility systems for heavy duty vehicles. From LED beacons to trailer connectors, Grote products provide effective solutions and added value to its customers in the agricultural, construction, freight, and mining industries. The company has been a major supplier to commercial vehicle manufacturers, utilizing the latest quality planning techniques and manufacturing systems as well as rigorous environmental testing to maintain their competitive edge. Grote also works closely with OEM distributors and fleet managers in developing new ways to maximize the efficiency of their products according to the demands of the market.
