COLE HERSEE part description

Cole Hersee toggle switches are manufactured in many different configurations. They're available with ball, short or long handles, paddle and illuminated actuators. Housing are plastic, plastic/metal combination or die cast. Weather resistant options are available that make any standard toggle switch adaptable for use in applications where moisture, dirt and similar elements are present.
Toggle switch accessories include weather resistant boots, face plates, switch guards, and handle extensions.
All products listed in this section can be found in Section B of the Cole Hersee D-275 CATALOG.
  • Up: On, Center: Off.
  • Terminals are arranged to match oemOriginal Equipment Manufacturer. In the automotive industry, this term refers to automotive and heavy vehicle manufacturers. However, generally it can also refer to the manufacturer of any finished product. wiring connectors. 59024-00 series available with or without brackets. Silver contactsA pair of devices that touch or come apart at the point where the switch throw makes or breaks the circuit. Silver contacts are common because of their low conductivity and low electrical resistance. Many Cole Hersee switches have silver contacts.. Black phenolic switch housing with metal cap. 15/32" -32 thread mounting stem. Fits panels to .093" (2.4mm) with spacer provided, or to .25" (6.4mm) without spacer. Includes mounting hardware: black metal facenut. keywayIn toggle switches, a groove cut across the threads of the mounting stem. Toggle switches are generally mounted ithrough a circular hole in the panel, and secured by tightening a nut against the panel. Sometimes the nut can loosen ciusing rotation of the switch. Some panels are pre-cut with holes that have a small projection which engages with the keyway, thus preventing potentiol switch rotation. is in the down position. Black plastic 1" (25.4mm) handle, matte finish. Four tin-plated blade terminals. 25A at 12V DC.
Switch type Toggle
Description Toggle Switch, Freightliner Replacement or General Usage
Circuitry DPST
Electrical Rating 25A at 12VDC
Contacts Silver
Housing Black plastic with metal cap
Up position On
Center position Off
Down position None
Terminals 4 tin-plated blade
Handle material Nylon, plastic, black
Handle type Paddle
Handle size: inches 1" Long
Handle size: mm 26.98mm
Mounting hardware Black finished face nut
Mounting stem material Black finished brass
Mounting stem dimmensions nickel plated brass, 15/32" -32 thread, .240" (6.09mm) long with keyway
Mounting hole dimension 15/32" (11.90mm) Panel Hole
Panel thickness Up to 3/32" (2.38mm) thick
Min qty No

COLE HERSEE 59024-14 Cross Reference

We have 2 alternatives for the 59024-14 by COLE HERSEE:

Cole Hersee® is highly valued in the heavy duty truck industry. It is a leading manufacturer of heavy-duty battery master switches that are widely used as OE equipment by leading heavy-duty vehicle manufacturers. These switches are essential safety components for trucks as they help prevent theft, tampering, electrical fires, and battery drain. Founded in 1924, Cole Hersee is committed to improving vehicle safety by partnering with ECCO Safety Group Australia (ESGA) to establish and implement safety standards for trucks that drive onto mining sites. Its products are also manufactured in its ISO 9001:2008-certified facility and undergo strict testing to ensure safety and reliability.
