DANA part description

NUT

Product Attributes

Series 1710
Material Steel
Spline Count 49
Type Splined Hole
Assembly Y
Hub Diameter R 3.819 IN
Includes Slinger/Plug Y
Involute Spline Y
Length Thru Hole Q 2.677 IN
Outside Yoke Dimension (In) E 6.094 IN
Yoke Bearing Dimension (In) D 1.938 IN
Yoke Style BP
Major Diameter 2.544 IN
C/L To End Hub S 6.050 IN
C-Bore Depth 0.240 IN

Additional Information

Country of Origin (Primary) MX
Harmonized Tariff Code (Schedule B) 8708990000
Harmonized Tariff Code (HTS) 8708990000
UPC 00023913217495
VMRS Code 022003072

Part Interchanges

DANA 131530K Cross Reference

We have 2 alternatives for the 131530K by DANA:

Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
